Arburg 370S 700-170, 2008
Product information "Arburg 370S 700-170, 2008"
terms of delivery: FCA Pegnitz
delivery time: on request
terms of payment: 100% prior to delivery
| 01-manufacturer: | Arburg |
|---|---|
| 02-type: | Arburg 370S 700-170 |
| 03-year of construction: | 2008 |
| 04-condition: | technisch überarbeitet |
| 05-operating hours: | ca. 73.000 |
| 10-CLAMPING UNIT: | - |
| 11-clamping force: | 70 t |
| 12-opening path: | 400 mm |
| 13-mould installation height min: | 200 mm |
| 15-tie bar distance (h x v): | 370 x 370 mm |
| 16-plate dimension (h x v): | 510 x 510 mm |
| 17-centering (fix- movingplate): | 125 / 125 mm |
| 20-INJECTION UNIT: | IU170 |
| 21-screw diameter: | 25 mm |
| 22-injection weight in polystyrol: | 45 g |
| 23-stroke volume: | 49 cm³ |
| 24-injection pressure: | 2.500 bar |
| 30-CONTROL: | Selogica direct |
| 31-screen language: | DE |
| 32-operating manuel: | DE |
| 40-EQUIPMENT: | Technologiestufe 2 / Technology Level 2 |
| 41-core pulls: | 1 |
| 42-air valves: | ja / yes |
| 43-hot runner control devices : | - |
| 44-robot interface: | Euromap 67 |
| 45-other equipment : | Siehe Auftragsspezifikation / see order specification |
| 50-GENERAL DATA: | - |
| 51-installed heating capacity: | 11 kW |
| 52-pump drive power: | 15 kW |
| 53-total installed power: | Motor + Heizung |
| 54-total weight: | 3.500 kg |
| 55-total size L x B x H: | 4,0 x 1,6 x 2,0 m |
