Ferromatik Milacron Maxima MM 650-3470, 2007
Product information "Ferromatik Milacron Maxima MM 650-3470, 2007"
terms of delivery: EXW (ex Works)
delivery time: on request
terms of payment: 100% prior to delivery
| 01-manufacturer: | Ferromatik Milacron |
|---|---|
| 02-type: | Maxima MM 650-3470 |
| 03-year of construction: | 2007 |
| 04-condition: | Running Production |
| 05-operating hours: | ca. 45.000 |
| 10-CLAMPING UNIT: | - |
| 11-clamping force: | 650 t |
| 12-opening path: | 1675 mm |
| 13-mould installation height min: | 400 mm |
| 14-mould installation height max.: | 1100 mm |
| 15-tie bar distance (h x v): | 1080 x 1080 mm |
| 16-plate dimension (h x v): | 1410 x 1410 mm |
| 17-centering (fix- movingplate): | 200/250 |
| 20-INJECTION UNIT: | IU3470 |
| 21-screw diameter: | 70 mm |
| 22-injection weight in polystyrol: | 1191 g |
| 23-stroke volume: | 1385 cm³ |
| 24-injection pressure: | 2.300 bar |
| 30-CONTROL: | Mosaic |
| 31-screen language: | DE / EN / FR |
| 32-operating manuel: | DE |
| 40-EQUIPMENT: | - |
| 41-core pulls: | 2 |
| 42-air valves: | 2x (Steuerung) |
| 43-hot runner control devices : | - |
| 44-robot interface: | Euromap 67 |
| 45-other equipment : | - |
| 50-GENERAL DATA: | - |
| 51-installed heating capacity: | 36 kW |
| 52-pump drive power: | 75+22 kW |
| 53-total installed power: | Motor + Heizung |
| 54-total weight: | 36.000 kg |
| 55-total size L x B x H: | 9,6 x 2,8 x 2,9 m |
