FM Elektra evolution EE110L-300, 2010 (Electric)
Product information "FM Elektra evolution EE110L-300, 2010 (Electric)"
terms of delivery: FCA Pegnitz
delivery time: on request
terms of payment: 100% prior to delivery
| 01-manufacturer: | Ferromatik Milacron |
|---|---|
| 02-type: | EE110L-300 |
| 03-year of construction: | 2010 |
| 04-condition: | Running Production |
| 05-operating hours: | ca. 55.000 |
| 10-CLAMPING UNIT: | - |
| 11-clamping force: | 110 t |
| 12-opening path: | 440 mm |
| 13-mould installation height min: | 200 mm |
| 14-mould installation height max.: | 590 mm |
| 15-tie bar distance (h x v): | 520 x 520 mm |
| 16-plate dimension (h x v): | 780 x 780 mm |
| 17-centering (fix- movingplate): | 125 mm |
| 20-INJECTION UNIT: | IU300 |
| 21-screw diameter: | 30 mm |
| 22-injection weight in polystyrol: | 103 g |
| 23-stroke volume: | 113 cm³ |
| 24-injection pressure: | 2.543 bar |
| 30-CONTROL: | Mosaic |
| 31-screen language: | DE |
| 32-operating manuel: | DE |
| 40-EQUIPMENT: | - |
| 41-core pulls: | 1 x hydr. |
| 42-air valves: | 1 x |
| 43-hot runner control devices : | 4 |
| 44-robot interface: | Euromap 67 |
| 45-other equipment : | Selektierweiche |
| 50-GENERAL DATA: | - |
| 51-installed heating capacity: | 11,2 kW |
| 52-pump drive power: | entfällt |
| 53-total installed power: | Motor + Heizung |
| 54-total weight: | 7.200 kg |
| 55-total size L x B x H: | 5,0 x 1,5 x 2,1 m |
