Henn Angußpicker HS500S
Product information "Henn Angußpicker HS500S"
terms of delivery: EXW (ex Works)
delivery time: on request
terms of payment: 100% prior to delivery
| 01-manufacturer: | Henn |
|---|---|
| 02-type: | HS500S |
| 03-year of construction: | 2016 |
| 04-condition: | funktionsgeprüft |
| 10-AXIS: | - |
| 11-X-axis: | 50 mm |
| 12-Y-axis: | 700 mm |
| 13-Z-axis: | 700 mm |
| 14-additional axes A-B-C: | Schwenkachse 50-90° |
| 15-load capacity: | 0,5 kg |
| 16-gripper: | 1 x |
| 17-vacuum: | - |
| 18-other equipment: | Luftanschluss: 4 - 5 bar (gefilterte Luft) / Pneumatik: Festo - SMC / Spannung: 100 - 240 VAC, 50 - 60 Hz |
| 20-CONTROL: | SPS |
| 21-screen language: | DE |
| 22-operating manuel: | DE |
| 23-safety device: | nein |
| 24-interface: | Euromap 12 |
| 31-adapter: | - |
| 32-prop for Z-axis: | - |
| 33-bore pattern + connection thread: | - |
| 34-safety device: | nein |
| 35-total weight: | 150 kg |
| 36-total size L x W x H: | 0,8 x 0,8 x 1,0 m |
| 37-total installed power: | 1,5 kW |
