Ersatzteile Spritzeinheiten gebraucht

Ferromatik Milacron mould movement cylinder K200-S

Ferromatik Milacron mould movement cylinder- removed from K200-S- removed from running machine- fully functionalmanufacturer: Ferromatik Milacron

€198.00*

Arburg 420 C nozzle guard IU60 complete / 210.459

Arburg 420 C nozzle guard IU60 - removed from Arburg 420 C- removed from running machine- fully functional manufacturer: Arburg spare part no.: 210459

€100.00*

Arburg device vertical injektion Ø 45 mm

Arburg device vertical injection Ø 45 mm- suitable for bar diameter 45 mm- suitable for tie bar distance injection unit 210 mm- removed from running machine- fully functionalmanufacturer: Arburg

€231.00*

Arburg heating band Ø 60 mm x 130 mm / 142.368

Arburg heating band - Ø 60 mm x 130 mm - 230 -250V / 800W- removed from IU60- removed from Arburg 420 C- removed from running machine manufacturer: Arburgspare part no.: 142368

€175.00*

Arburg heating band Ø 60 mm x 130 mm / 158.462

Arburg heating band - Ø 60 mm x 130 mm - 230 -250V / 1250W- removed from IU60- removed from Arburg 420 C- removed from running machine manufacturer: Arburgspare part no.: 158462

€175.00*

Arburg heating band Ø 70 mm x 100 mm, 200 - 240 V, 900 W / 107.591

Arburg heating band Ø 70 mm x 100 mm, 200 - 240 V, 900 W- removed from Arburg A270M 500-90- removed from running machine- fully functionalmanufacturer: Arburgsparepart no.: 107.591

€116.00*

Arburg injection unit IU30, Ø 12 mm / 209.030

Arburg injection unit IU30, Ø 12 mm- removed from Arburg Allrounder 275 V 250 - 30- bonded- fully functional- with cylinder and screw Ø 12 mmmanufacturer: Arburgtype:IU30

€4,043.00*

Arburg IU350 Plastifiziereinheit, Ø 40 mm / 124.098

Arburg IU350 plasticising unit - Ø 40 mm- wear-resistant- removed from Arburg A520C 1600-350V- removed from running machine- fully functional - displacement: 182 cm³- Injection pressure: 2120 bar- maximum moulded part weight: 166 g screw:inlet: 39.76 mmcentre: 39.75 mmoutlet: 39.69 mmRSP: 39.98 mmtotal length: 109.50 cm cylinder:inlet: 40.04 mmcentre: 40.02 mmoutlet: 40.03 mmtotal length: 108.20 cm manufacturer: Arburgtype: IU350spare part no.: 124.098 (unit), 132.127 (screw)

€3,800.00*

Arburg nozzle head Ø 8 mm

rburg nozzle head Ø 8 mm- thread: M24 x 1- removed from IU60- removed from Arburg 420 C- removed from running machinemanufacturer: Arburg

€125.00*

Arburg nozzle heating band Ø 50 x 35 mm / 230V 310W / 46.334

Arburg nozzle heating band Ø 50 x 35 mm / 230V 310W- removed from a running machine- fully functionalmanufacturer: Arburgspare part no. 46.334

€100.00*

Arburg nozzle heating band Ø 50 x 40 mm / 200-240V 600W / 108.254

Arburg nozzle heating tape Ø 50 x 40 mm - Ø 50 x 40 mm- 200-240V 600W- removed from running machine- fully functional manufacturer: Arburgspare part no.: 108.254

€100.00*

Arburg open nozzle Ø 18 mm / 211.047

Arburg open nozzle Ø 18 mm- thread: M36 x 2- left-hand thread- removed from IU60- removed from Arburg 420 C- removed from running machinemanufacturer: Arburgspare part no.: 211.047

€125.00*

Arburg open nozzle Ø 25 mm

Arburg open nozzle Ø 25 mm- thread: M36 x 2- left-hand thread- removed from IU60- removed from Arburg 420 C- removed from running machinemanufacturer: Arburg

€150.00*

Arburg plasticising screw IU60 Ø 18 mm / 189.258 - mit RSP

Arburg plasticising screw Ø 18 mm - with screw tip- screw diameter: 18 mm- removed from IU60- removed from Arburg 420 C- removed from running machine- fully functional inlet: 17.78 mmcentre: 17.78 mmoutlet: 17.79 mmscrew tip: 17.96 mmtotal length: 67,50 cm manufacturer: Arburgspare part no.: 189.258

€750.00*

Arburg plasticising unit IU60 Ø 18 mm / 148.632 - with screw tip

Arburg plasticising unit IU60- with screw tip- screw diameter: 18 mm- removed from Arburg 420 C- removed from running machine- fully functionalcylinder:inlet: 18.02 mmcentre: 18.01 mmoutlet: 18.01 mmtotal length: 67.00 cmscrew:inlet: 17.76 mmcentre: 17.76 mmoutlet: 17.79 mmscrew tip: 17,95 mmtotal length: 67.50 cm- displacement: 20 cm³- injection pressure: 2500 bar- moulded part weight max. PS: 18 gmanufacturer: Arburgtype: IU60 spare part no.: 148632

€2,250.00*

Arburg plasticising unit IU60 Ø 18 mm / 148.632 - with screw tip

Arburg plasticising unit IU60- with screw tip- screw diameter: 18 mm- removed from Arburg 420 C- removed from running machine- fully functionalcylinder:inlet: 18.05 mmcentre: 18.05 mmoutlet: 18.02 mmtotal length: 67.00 cmscrew:inlet: 17.76 mmcentre: 17.78 mmoutlet: 17.76 mmscrew tip: 17,96 mmtotal length: 67.50 cm- displacement: 20 cm³- injection pressure: 2500 bar- moulded part weight max. PS: 18 gmanufacturer: Arburgtype: IU60spare part no.: 148632

€2,250.00*

Arburg plasticising unit IU60 Ø 18 mm / 148.632 - with screw tip

Arburg plasticising unit IU60- with screw tip- screw diameter: 18 mm- removed from Arburg 420 C- removed from running machine- fully functionalcylinder:inlet: 18.03 mmcentre: 18.02 mmoutlet: 18.02 mmtotal length: 67.00 cmscrew:inlet: 17.76 mmcentre: 17.78 mmoutlet: 17.74 mmscrew tip: 17,97 mmtotal length: 67.50 cm- displacement: 20 cm³- injection pressure: 2500 bar- moulded part weight max. PS: 18 gmanufacturer: Arburgtype: IU60 spare part no.: 148632

€2,250.00*

Arburg plasticising unit IU60 Ø 18 mm / 148.632 - with screw tip

Arburg plasticising unit IU60- with screw tip- screw diameter: 18 mm- removed from Arburg 420 C- removed from running machine- fully functionalcylinder:inlet: 18.04 mmcentre: 18.03 mmoutlet: 18.02 mmtotal length: 67.00 cmscrew:inlet: 17.86 mmcentre: 17.81 mmoutlet: 17.86 mmscrew tip: 17,97 mmtotal length: 67.50 cm- displacement: 20 cm³- injection pressure: 2500 bar- moulded part weight max. PS: 18 gmanufacturer: Arburgtype: IU60 spare part no.: 148632

€2,250.00*

Arburg plasticising unit IU60 Ø 18 mm / 148.632 - without screw tip

Arburg plasticising unit IU60- without screw tip- screw diameter: 18 mm- removed from Arburg 420 C- removed from running machine- fully functionalcylinder:inlet: 18.03 mmcentre: 18.08 mmoutlet: 18.04 mmtotal length: 67.00 cmscrew:inlet: 17.80 mmcentre: 17.77 mmoutlet: 17.82 mmtotal length: 67.50 cm- displacement: 20 cm³- injection pressure: 2500 bar- moulded part weight max. PS: 18 gmanufacturer: Arburgtype: IU60spare part no.: 148632

€2,100.00*

Arburg plasticising unit IU60 Ø 25 mm - mit RSP

Arburg plasticising unit IU60- with RSP- Screw diameter: 25 mm- removed from Arburg 420 C- removed from running machine- fully functionalcylinder:Inlet: 25.00 mmcentre: 25.00 mmoutlet: 25.01 mmtotal length: 67.00 cmscrew:Inlet: 24.85 mmCentre: 24.89 mmOutlet: 24.93 mmtotal length: 67.50 cm- Displacement: 39 cm³- Injection pressure: 1810 bar- Moulded part weight max. PS: 36 gmanufacturer: Arburgtype: IU60

€3,210.00*

Arburg screw + RSP Ø 30 mm / IU150 / 121.593

Arburg screw with screw-tip - from IU150- Ø 30 mm - inlet: 29.75 mm- centre: 29.70 mm - outlet: 29.80 mm- RSP: 29.94 mm- removed from Arburg Allrounder 320S 500-150- removed from running machine- fully functional manufacturer: Arburgspare part no.: 121.593

€1,350.00*

Arburg screw-in nozzle Ø 30 mm für IU150 / 157.502

Arburg screw-in nozzle für IU150 - thread: 150 x 2- left-hand thread- removed from Arburg 320S 500-150- removed from running machine- fully functional manufacturer: Arburgspare part no.: 157.502

€495.00*

Arburg thermal element 650 / 147.835

Arburg temperature sensor 650 - Ø 6.5 mm- closure Ø 12 mm- thread: M12 x 1.5- SW 13- removed from Arburg 420 C- removed from running machine manufacturer: Arburgspare part no.: 147.835

€50.00*

Arburg thermal sensor Ø 12 mm / 77.007

Arburg temperature sensor - Ø 12 mm- removed from Arburg- removed from running machine- fully functional manufacturer: Arburgspare part no.: 77.007

€45.00*
